Supported vehiclesįollowing list shows all vehicles for which is key teaching supported: Manufecture

#2002 hyundai elantra ecu diagnostic work near me code

Vehicle PIN code can be obtained through service or through Hyundai dealer.

For smart key (proximity) leave car alone with good battery charge for 1 hour.

For mechanical keys leave key on for 1 hour.

If you enter incorrect pin 3 times the immobilizer (SMARTRA or Smart key) will lock In order to unlock:

When a key is lost and needs to be deleted.

When replacing with new ECM or used ECM (neutralized ECM).

PIN code is needed when the teaching new ECM and new keys, e.g. The PIN code is a unique code for each vehicle and it is programmed into ECM at production line. PIN code stands for of Product Identification Number code. The vehicle specific data are written into the transponder memory. The data of all transponder, which are valid for the vehicle, are stored in the ECM.ĭuring the key teaching procedure the transponder will be programmed with vehicle specific data. Only if the results are equal the engine can be started. The ECM carries out the check of ignition key by special encryption algorithm, which runs in the transponder and in the ECM in parallel. The immobilizer system consists of the ECM, the SMARTRA, the lamp and ignition keys with built-in transponder. The multiplexer is a part of ECM hardware.

The ECM controls the communication either to SMARTRA or diagnostic equipment on K line by switching of a multiplexer and specific communication procedures. During communication of ECM and SMARTRA the K line of ECM cannot be used for communication. The SMARTRA communicates to a engine control module via a dedicated communications line (called W-Line, or Immo-Line).

#2002 hyundai elantra ecu diagnostic work near me serial

This device is only an advanced interface, which converts the RF data flow (radio frequency of 125 kHz) of transponder into serial communication to ECM and vice versa. The SMARTRA does not carry out the check of validity of transponder or the calculation of encryption algorithm. The SMARTRA unit contains an integrated inductive antenna and electronics around the ignition lock assembly. The SMARTRA stands for SMARt TRansponder Antenna.
